DESCRIPTION

Overview

Basic Info.

Model NO.	Junction Box Making Machine
Certification	ISO, CE
Automation	Automation
Flexible Production	Intelligent Manufacturing
Rhythm	Flow Production Line
Production Scope	Product Line
After-sales Service	Overseas After-Sales Service
Key Selling Points	Automatic
Warranty of Core Components	24 Months
Showroom Location	Egypt, Canada, United Kingdom, Viet Nam, Mexico, T
Core Components	Bearing, Pump, Gear, Motor, Gearbox, PLC, Pressure
Mould	Customized
Voltage	220V/380V/415V Customization
Machinery Test Report	Provided
Applicable Industries	Building Material Shops, Manufacturing Plant
Usage	Pressing Metal Products
Marketing Type	New Product 2023
Video Outgoing-Inspection	Provided
Power Press Machine	Punching Machine Auto Line
Function	Punching Power Press
Product Name	Junction Box Making Machine Production Line
CNC or Not	CNC, Normal
Transport Package	Standard Export Packaging
Specification	Customized
Trademark	BESCOMT
Origin	Shandong
HS Code	8428399000
Production Capacity	100+

Packaging & Delivery

Package Size 95.00cm * 26.00cm * 40.00cm Package Gross Weight 22000.000kg

Product Description

Automatic C-frame Double Point Sheet Metal Power Press Punching Machine for Electrical Junction Box Making Stamping Machine Complete solution

metal switch junction conduit socket box making punching machine

1.The machine body is welded of quality steel sheet and treated by tension elimination, improve stability and reliability of precision of the machine. 2.In order to guarantee the machine running in stable and smooth,adopts the design of symmetrical two slid boards with balancer.3.The precision of mold adjusting up to 0.1mm,safety,reliable and convenient.4.Crank,gear,connectbar are oxidized hardening and milled, having super comprehensive mechanical performance and durable function. 5.Reasonable structural design, is convenient for automatic production and line production.6.Used reliable high intensity clutch/brake and twin electromagnetic vale, overloading protector can guarantee safe production all-around.7.Used high-grade alloy steel, double crank, wide work center with connection bar structure, the optimized design is suitable for large sizes and the mold bearing large impact loading as well as pressing of eccentric mold.8.Adopted closed electric loop circuit, have compatible with any automatic equipments.
Keywords: Junction box production line,Junction box making machine,BLC punching machine,Double Crank open type High precision pneumatic press machine

Punching Machine

Double Crank Open Type High Precision Pneumatic Press Machine--BLC
Specification		BLC100	BLC160	BLA200	BLC250	BLC315
Model		V/H	V/H	V/H	V/H	V/H
Capacity	Ton	110	160	200	250	315
Rate tonnage point	mm	5/3	6/3	6/3	7/3.5	7/3.5
Stable speed	s.p.m	35-65/50-100	30-55/40-85	25-45/35-70	20-35/30-60	20-35/30-50
Stroke	mm	180/110	200/130	250/150	280/170	300/170
Die height	mm	400/435	450/485	500/550	550/605	550/615
Slider adjustment	mm	100	100	120	120	120
Slider area	mm	1400*500*70	1600*550*70	1850*650*95	2100*700*95	2100*700*95
Bolster area	mm	1800*650*130	2000*760*150	2400*840*170	2700*900*170	2750*900*190
Main motor	kw.p	11*4	15*4	18.5*4	22*4	30*4
Air pressure	kg/cm²	6
Presses precison		GB/JIS 1class
Presses dimension	mm	1745*2000*3059	1940*2200*3709	2235*2620*3849	2545*3000*4303	2545*3010*4689
Die cushion capacity	Ton	14.2	20	27.5	45.5	48
Die cushion work part dimension	mm²	350*235*2groups	410*260*2groups	540*350*2groups	640*470*2groups	640*470*2groups

Electric Control Cabinet PLC Converter

Hydraulic overload protector Clutch Automatic lubrication installation

Feeder System

Click to NC Servo Feeder

1.The machine body is welded of quality steel sheet and treated by tension elimination, improve stability and reliability of precision of the machine.
2.In order to guarantee the machine running in stable and smooth,adopts the design of symmetrical two slid borards with balancer.

Click to 2 in 1 machine
Decoiler and straightener 2 in 1 machine is widely used in stamping and cutting of hardware, stamping, electronics, electrical appliances, science and technology, auto parts, metal, packaging, industry, precision, aviation, cabinets, automotive, science and technology, machinery, electrical, mechanical and other industries.

Mould

Long Life Container Making Mould

Mold Material: Mold Carrier And Mold Core DC-53 ,SKD11 etc. Pruning Wound DC-53 , SKD11 From Japan Mold Life Time: 20000000 Times.
In Short, we can provide you both products and molds in Best Quality.
All of our products and molds are 100% designed and made in our factory.
We are confident to satisfy our customers with best value of mold making workmanship.

Company Profile

We are currently reviewing our product packaging from the angles of waste-reduction and resource-saving. We are also working on improving transportation efficiency from the design phase of product development.
1.Our wooden case is after fumigation treatment. Needn't timber inspection, saving shipping time.
2.All the spare parts of the machine were covered by the some soft materials mainly using pearl wool.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack, convenient to handing and transport.

After Sales Service

1.Global after-sales service We dispatch engineers to provide on-site servicescustomer.2.We can send the component by DHL, TNT freelyOur guarantee time is two years, if any component is damaged during guarantee time
3.Our factory can send our engineer to the customer's factory install, commission and training freelyThe customer provide the double trip tickets, food and accommodation for our engineer. The customer also can send the engineer to
our factory to learn the operation and maintains freely.

FAQ

1.Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis /Conformance; Insurance; Origin, and other export documents where required.
2.What kinds of payment methods do you accept?
You can make the payment to our bank account, Western Union or PayPal:30% deposit in advance, 70% balance before delivery 3.Guaranty covers?
Main parts of the machine , wearing parts not included .PARTS DELIVERY. Within 5 days by DHL / Fexed . 4.About our after-sale service:
Customer service 24 hours online, you can send technicians to your country to repair the machine. Buyer shall bear all costs including visa, round trip airfare and suitable accommodation and buyer shall pay usd 100 / day salary.
5.How to replace machine parts?
Parts adopt international brands, good quality, no need to replace within 3-5 years, convenient to buy suitable parts locally.
6.Installation&Commissioning:
Usually solved by video conference, if necessary, can be dispatched to the door installation debugging and maintenance of technical personnel.
